3500W Solar inverter System
3500W Solar inverter System-1

3500W Solar inverter System

1. Pure sine wave inverter with C.R.G.O. transformer, lower static loss;

2. With solar and AC charger together;

3. Three stage intelligent Automatic Charging Technology to protect battery;

4. High efficient DC to AC conversion, minimizing energy loss;

5. Overload, short circuit protection, overcharging, over-discharging protection;

6. The system working days is based on 8 hours strong sunshine

Categories: Solar Power System

3500W Solar Power System technical data
System Capacity 3500W
System voltage 48Vdc
Best output power everyday 12000WH*
Inverter Output wave Pure Sine Wave
Rated power 3500W
Output voltage AC220V
Output frequency 50Hz-60Hz
Input voltage range 140V-275Vac
Output voltage range 195V-240Vac
Charge current 15A
Solar charger controller Rated working voltage 48V
Rated charge current 60A(max.)
PV input range 60V-100Vdc
Solar panel Pmax 200W
 Vimp 37.6V
 Imp 5.31A
Battery  (Battery) capacity 12V/150Ah
 (Battery) type Maintenance-free lead acid
Componets Specification QTY
Solar Panel 200W 10PCS
Battery 12V/150Ah 8PCS
Inverter 2100W/48V 1PCS
Wire 8mm square, 20M 2PCS
